Power your home, business, or off-grid solar installation with the MUST PV19-12048 EXP PRO 12kW Hybrid Solar Inverter. Designed for high-performance solar energy systems, this advanced inverter combines a pure sine wave inverter, dual MPPT solar charge controllers, intelligent battery charging, and UPS functionality in a single unit.
With 12,000W continuous output, 24,000W surge capacity, and support for up to 6 units in parallel, it is ideal for large residential and commercial solar applications. The inverter operates with or without batteries, supports lithium battery BMS communication, and features a smart LCD display with USB, RS485, and optional WiFi monitoring for complete system control.
AED 2,500.00
≈ $681
Available on Request
Available on Request
Description
Key Features
Dual MPPT Trackers: Models from 6.2KW to 12KW feature Dual MPPT inputs, allowing for two independent solar strings. This maximizes energy harvest from different roof orientations and supports higher total PV input power (up to 12000W on the largest model).
Smart Dual Output: Equipped with main and secondary AC outputs to automatically manage loads—keeping critical devices running while shedding non-essential loads during low battery conditions.
Massive Power & Scalability: Offers single-unit power up to 12KW and supports Parallel operation for up to 6 units, capable of creating a powerful 72KW three-phase or single-phase system.
High Voltage PV Input: Supports a Maximum PV Open Circuit Voltage of 500VDC, reducing installation costs by allowing longer series strings of solar panels.
User-Friendly Interface: Features a Color LCD display with touch buttons and built-in WiFi/USB/RS485 interfaces for easy monitoring and configuration.
Lithium Battery Ready: Advanced BMS communication ensures safe and efficient charging of lithium battery banks, with a wide MPPT voltage range for optimal performance.
Specification
Overview
| Weight | 15.5 kg |
|---|---|
| Dimensions | 55 × 40 × 22 cm |
| Model | PV19-12048 EXP PRO |
| Rated Power | 12000VA / 12000W |
| Surge Power | 24000W |
| Battery Voltage | 48V DC |
| Output Waveform | Pure Sine Wave |
| AC Output Voltage | 220V / 230V / 240V AC |
| AC Input Voltage | 230V AC |
| Output Frequency | 50Hz / 60Hz Auto |
| Peak Efficiency | Up to 98% |
| Transfer Time | 10ms (UPS Mode) |
| MPPT Controllers | Dual MPPT |
| MPPT Voltage Range | 90V – 450V DC |
| Maximum PV Input Voltage | 500V DC |
| Maximum PV Power | 6000W × 2 (12kW Total) |
| Maximum PV Input Current | 27A × 2 |
| Maximum Solar Charge Current | 150A |
| Maximum AC Charge Current | 150A |
| Maximum Combined Charge Current | 150A |
| Parallel Operation | Up to 6 Units |
| Battery Compatibility | Lithium, AGM, GEL, Lead Acid |
| Communication | USB, RS485, CAN, Optional WiFi |
| BMS Support | Yes |
| Display | Smart LCD |
| Mounting Type | Wall Mount |
| Protection | Overload, Short Circuit, Deep Discharge |
| Certification | CE, EMC, LVD |
