Power your IP cameras, wireless access points, VoIP phones, and other PoE-enabled devices with the Ruijie Reyee RG-ES106D-P V2. This compact 6-port Gigabit unmanaged switch features 4 PoE+ ports, 2 Gigabit uplink ports, and a 54W PoE power budget, making it ideal for small businesses, offices, retail stores, and home surveillance systems. With true plug-and-play installation, intelligent PoE power management, and fanless silent operation, it delivers reliable, high-speed networking without configuration.
AED 273.50
≈ $75
In stock
In stock
Description
Key Features
- 6 × 10/100/1000Mbps Gigabit Ethernet ports
- 4 × IEEE 802.3af/at PoE+ ports
- 2 × Gigabit uplink RJ45 ports
- 54W total PoE power budget
- Up to 30W PoE output per port
- Plug-and-play unmanaged operation
- Fanless silent design
- Auto MDI/MDIX support
- Store-and-forward switching architecture
- Supports jumbo frames for improved performance
- Intelligent PoE power management
- Compact desktop or wall-mount installation
- Energy-efficient operation
- Ideal for IP cameras, wireless access points, VoIP phones, and IoT devices
Specification
Overview
| Weight | 0.90 kg |
|---|---|
| Dimensions | 27 × 16 × 6 cm |
| Item Dimension | 20 x 10.8 x 2.8 cm |
| Item weight | 0.56 kg |
| Model | RG-ES106D-P V2 |
| Product Type | Unmanaged Gigabit PoE Switch |
| Switching Capacity | 12 Gbps |
| Forwarding Rate | 8.93 Mpps |
| Ports | 6 × Gigabit RJ45 |
| Uplink Ports | 2 × Gigabit RJ45 |
| PoE Standard | IEEE 802.3af / IEEE 802.3at |
| Max PoE per Port | 30W |
| Packet Buffer | 1.5 Mb |
| Jumbo Frame | Up to 9 KB |
| Switching Method | Store-and-Forward |
| Auto Negotiation | Yes |
| Auto MDI/MDIX | Yes |
| Flow Control | IEEE 802.3x |
| Installation | Desktop / Wall Mount |
| LED Indicators | Power, Link/Activity, PoE Status |
| Housing Material | Metal |
| Power Supply | External Power Adapter |
| Input Voltage | 100–240V AC, 50/60Hz |
| Power Consumption | Maximum approximately 60W |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -40°C to 70°C |
| Operating Humidity | 10%–90% RH (Non-condensing) |
| Certifications | CE, FCC, RoHS |
