Cisco Catalyst C9500-16X-E 16-Port 10G Enterprise Switch | Layer 3 Core Aggregation | 480 Gbps | IOS XE Network Essentials
-
Pick up from the Ultra Smart Store
To pick up today
Free
-
Courier delivery
Our courier will deliver to the specified address
2-3 Days
From $40
-
DHL Courier delivery
DHL courier will deliver to the specified address
1-2 Days
From $40
The Cisco Catalyst C9500-16X-E is a high-performance, enterprise-class fixed core and aggregation switch designed for modern campus networks. Built on Cisco’s advanced IOS XE platform, it delivers powerful Layer 2 and Layer 3 capabilities, automation support, and strong security features for scalable enterprise deployments.
With 16 x 10 Gigabit Ethernet ports, high switching capacity, and advanced programmability, this switch is ideal for enterprise backbone, data center aggregation, and high-density campus environments requiring reliable, high-speed connectivity.
Engineered for performance, security, and scalability, the C9500-16X-E supports full stack automation, advanced routing protocols, and enterprise-grade resiliency features.
AED 22,950.00
≈ $6253
Available on Request
Available on Request
Description
Key Features
- 16 x 10G SFP+ high-speed ports
- Up to 480 Gbps switching capacity
- Up to 360 Mpps forwarding rate
- Enterprise Layer 2 & Layer 3 full routing support
- Cisco IOS XE with programmability & automation (NETCONF, RESTCONF, gRPC)
- Advanced security: ACLs, MACsec, TrustSec-ready architecture
- 1RU fixed form factor for rack efficiency
- Designed for campus core and aggregation layers
- High scalability: up to 64,000 MAC entries and IPv4 routes
- Redundant power supply support for high availability
Dimensions & Weight
- Dimensions (H x W x D): 1.73 x 17.5 x 21.52 in (4.4 x 44.5 x 54.6 cm)
- Rack Units: 1RU
- Weight: ~23.6 lb (10.7 kg) with power supplies
Technical Specifications
Performance
- Switching capacity: up to 480 Gbps
- Forwarding rate: up to 360 Mpps
- MAC address table: up to 64,000
- IPv4 routes: up to 80,000 (host routes)
- IPv6 routes: up to 40,000
- Jumbo frame support: up to 9198 bytes
Hardware
- CPU: Multi-core x86 architecture
- RAM: 16 GB DRAM
- Flash storage: 16 GB
- Power supply: PWR-C4-950WAC-R / DC options
- Max power rating: 950W
Networking & Features
- VLANs: up to 4,000
- Switched Virtual Interfaces (SVIs): up to 4,000
- ACL scale: up to 18,000 (QoS & Security)
- NetFlow: up to 512,000 entries
- Full routing protocols: OSPF, BGP, EIGRP, IS-IS
- Automation: NETCONF, RESTCONF, gNMI, YANG models
- Security: TrustSec, MACsec, Secure Boot
Environment
- Operating temperature: 0°C to 40°C
- Storage temperature: -20°C to 65°C
- Humidity: 5% to 90% non-condensing
Ideal Use Cases
- Enterprise core switching
- Campus aggregation layer
- Data center access/edge
- High-performance enterprise WAN edge
- Secure enterprise network infrastructure
